Product Description:

BioXTEND® In-Transit Temperature Recorders

Temperature recorder
The BioXTENDSingle-user Temperature Recorder displays an ongoing Temperature/Time Chart of in-transit perishable goods. The Economical & User-Friendly Temperature Monitoring Solution provides accurate data of the temperature throughout the cold chain.

Available Models
Model Number Recording Period
BXTR-10 10-Day
BXTR-30 30-Day
BXTR-60 60-Day
BXTR-90 90-Day

Key Benefits

  • Reliable
  • Highly Accurate
  • Cost Efficient
  • User Friendly
  • Dual scale °F/°C chart
  • Serial number on each unit for traceability
  • Trilingual operation instructions: English, Spanish, French
  • Patented design guarantees recording trace stops at end of trip
  • Vented case for superior air circulation and faster temperature response



SPECIFICATIONS:

Specification Data
Temperature Range -28ºC to +38ºC (-20ºF to 100ºF)
Sensor Bi-metal coil, calibrated NIST (HACCP requirement)
Accuracy +/- 1ºC (+/-2ºF)
Chart Pressure sensitive, total length 91.4cm (36 in.), dual scale Cº/Fº
Drive Solid state quartz motor
Time Keeping Accuracy/Clock Motor Average +/-20 seconds a month
Battery AA Zinc chloride
Shelf Life 2 years
Dimensions 13,5 x 10 x 6,3 cm (5.5 in x 4 in. X 2.5 in.)
Weight 244 grams (8.6 oz.)
Case lot size/weight 20 recorders per case (5.4kg/12 lbs.)
Certification/calibration CE mark by T.U.V., traceable to N.I.S.T.
Models 10, 30, 60 and 90 Days
*Manufactured under ISO 9000 Registered Quality Management System US Patent No. 4,990,940

Instructions for Use:

User Guide

Download the BioXTEND® "How to Read a Chart" User Guide
